Wecon PLC Model: PI 3070N
◇ Hardware: CORTEX A8 600MHZ CPU, 128M FLASH, 128M DDIII RAM
◇ Display size: 7 inch
◇ Resolution: 800×480 TFT LCD 16,000Kcolors
◇ Interface: RS232/RS485/RS422 (2 COM ports available),one Ethernet port
◇ Storage: Support Date Storage, SD Card， U Disk
◇ Programmed by PI Studio
◇ WINCE7.0 LINUX supported
Out of stock
Wecon PI 7 inch HMI : PI3070N
◇ Hardware: CORTEX A8 600MHZ CPU, 128M FLASH, 128M DDIII RAM
◇ Display size: 7 inch
◇ Resolution: 800×480 TFT LCD 16,000Kcolors
◇ Interface: RS232/RS485/RS422 (2 COM ports available),one Ethernet port
◇ Storage: Support Date Storage, SD Card， U Disk
◇ Programmed by PI Studio
◇ WINCE7.0 LINUX supported
Specification
Physical & Electrical
| Series | PI8000 | PI8000 | PI8000 | PI8000 | PI8000 | PI8000 | |
| Model | PI8102H | PI8102H+ | PI8102H-R | PI8102H-R+ | PI8102H-Q+ | PI8102H-CE | |
| Main | OS | Linux 3.2.0 QT based | Linux 3.2.0 QT based | Linux 3.2.0 QT based | Linux 3.2.0 QT based | Linux 3.2.0 QT based | Wince 7.0 |
| Processor | Cortex A8 600MHz | Cortex A8 600MHz | Cortex A8 600MHz | Cortex A8 600MHz | Cortex A8 600MHz | Cortex A8 600MHz | |
| Display | Size | 10.2″ | 10.2″ | 10.2″ | 10.2″ | 10.2″ | 10.2″ |
| Screen | TFT | TFT | TFT | TFT | TFT | TFT | |
| Resolution | 1024*600 | 1024*600 | 1024*600 | 1024*600 | 1024*600 | 1024*600 | |
| Color | 16,000k colors | 16,000k colors | 16,000k colors | 16,000k colors | 16,000k colors | 16,000k colors | |
| Brightness (cd/m2) | 350 | 350 | 350 | 350 | 350 | 350 | |
| Backlight | LED | LED | LED | LED | LED | LED | |
| Backlight Lifetime | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | |
| Touch Panel | High precision four-wire resistive | High precision four-wire resistive | High precision four-wire resistive | High precision four-wire resistive | High precision four-wire resistive | High precision four-wire resistive | |
| Storage | Memory | 512 MB | 512 MB | 512 MB | 512 MB | 512 MB | 512 MB |
| Flash | 2 GB | 2 GB | 2 GB | 2 GB | 2 GB | 2 GB | |
| SD Card Slot | Yes | Yes | Yes | Yes | Yes | Yes | |
| USB Port | USB2.0 Host + USB2.0 Client | USB2.0 Host + USB2.0 Client | USB2.0 Host + USB2.0 Client | USB2.0 Host + USB2.0 Client | USB2.0 Host + USB2.0 Client | USB2.0 Host + USB2.0 Client | |
| RTC | Real-time clock | Yes | Yes | Yes | Yes | Yes | Yes |
| Calendar | Yes | Yes | Yes | Yes | Yes | Yes | |
| I/O Port | COM1 | CN1:RS422/RS485 CN2: RS232 |
CN1:RS422/RS485 CN2: RS232 |
CN1:RS422/RS485 CN2: RS232 |
CN1:RS422/RS485 CN2: RS232 |
CN1:RS422/RS485 CN2: RS232 |
CN1:RS422/RS485 CN2: RS232 |
| COM2 | CN1:RS485 CN2: RS232 |
CN1:RS485 CN2: RS232 |
CN1:RS485 CN2: RS232 |
CN1:RS485 CN2: RS232 |
CN1:RS485 CN2: RS232 |
CN1:RS485 CN2: RS232 |
|
| COM3 | RS485 | RS485 | RS485 | RS485 | RS485 | RS485 | |
| Ethernet | x1 | x1 | x1 | x1 | x1 | x1 | |
| CANopen | Optional | Optional | Optional | Optional | Optional | Optional | |
| Wi-Fi | — | — | — | — | — | — | |
| 4G LTE | — | — | — | — | — | — | |
| Power | Rated Power | < 10W | < 10W | < 10W | < 10W | < 10W | < 10W |
| Power Voltage | DC 24V | DC 24V | DC 24V | DC 24V | DC 24V | DC 24V | |
| Input range | DC 12 ~ 28V | DC 12 ~ 28V | DC 12 ~ 28V | DC 12 ~ 28V | DC 12 ~ 28V | DC 12 ~ 28V | |
| Shell Color | Grey | Grey | Grey | Grey | Grey | Grey | |
| Enclosure | Shell Material | ABS | ABS | ABS | ABS | ABS | ABS |
| Overall Size (mm) | 271.8W*190.4H*41.2D | 271.8W*190.4H*41.2D | 271.8W*190.4H*41.2D | 271.8W*190.4H*41.2D | 271.8W*190.4H*41.2D | 271.8W*190.4H*41.2D | |
| Mounting Size (mm) | 260.0W*179.0H | 260.0W*179.0H | 260.0W*179.0H | 260.0W*179.0H | 260.0W*179.0H | 260.0W*179.0H | |
| Mounting Method | Panel Mount | Panel Mount | Panel Mount | Panel Mount | Panel Mount | Panel Mount | |
| Weight (Kg) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | |
| Environment | Working Temperature | -10 ~ 60°C | -10 ~ 60°C | -10 ~ 60°C | -10 ~ 60°C | -10 ~ 60°C | -10 ~ 60°C |
| Storage Temperature | -30 ~ 70°C | -30 ~ 70°C | -30 ~ 70°C | -30 ~ 70°C | -30 ~ 70°C | -30 ~ 70°C | |
| Humidity | 10 ~ 90％RH (Non-condensing) | 10 ~ 90％RH (Non-condensing) | 10 ~ 90％RH (Non-condensing) | 10 ~ 90％RH (Non-condensing) | 10 ~ 90％RH (Non-condensing) | 10 ~ 90％RH (Non-condensing) | |
| Vibration Resistance | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | 10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes) | |
| Cooling | Air Cooling | Air Cooling | Air Cooling | Air Cooling | Air Cooling | Air Cooling | |
| Software | Programming | PIStudio | PIStudio | PIStudio | PIStudio | PIStudio | wince |
| Remote Access | — | — | WAN | WAN | — | — | |
| Email Alarm | — | — | — | — | YES | — | |
| IP Camera | — | — | — | — | YES | — | |
| Audio Output | — | — | — | — | — | — | |
| Video Player | — | — | — | — | — | — | |
| Data Tool | Yes | Yes | Yes | Yes | Yes | Yes | |
| Certificates | IP Code | IP65 (Front panel) | IP65 (Front panel) | IP65 (Front panel) | IP65 (Front panel) | IP65 (Front panel) | IP65 (Front panel) |
| CE | CE Marked | CE Marked | CE Marked | CE Marked | CE Marked | CE Marked | |
| FCC | FCC Class A | FCC Class A | FCC Class A | FCC Class A | FCC Class A | FCC Class A | |
| UL | — | — | — | — | — | — |
